FlashRunner Programmers (discontinued)

The basic FlashRunner technology that has been the source of SMH's commercial success has reached its age. Due to the fact that its’ new generations fully cover the spectrum of market requirements, the manufacturer decided to discontinue the production of these oldest instruments, with the exception of the FlashRunner Cube. However, SMH still supports users with new algorithms and accessories. Apologizing for the inconvenience to those customers who would like to replicate existing designs, we indicate possible replacements below.

FlashRunner Cube

• 2-channel (FRC_GP_02) / 4-channel (FRC_GP_04) / 8-channel (FRC_GP_08) ISP programmer;
• universal;
• programming algorithms offered separately;
• unit for integration within ATE;
• interface: LAN, RS-232;
• stand-alone and remotely controlled by PC modes;
• power supply 12 - 25V DC
  (power supplier not included);
• support of most ISP protocols (BDM, JTAG, SPI, I2C, MON, ICC, SCI, UART);
• wide spectrum of accessories – relay barriers, multiplexers;

FlashRunner Quatro Cable Interface

For FlashRunner Quatro programmer a cable interface is available as an external accessories:

• FR04INTF16 - for 16 channels

FlashRunner I, II, III Cable Interface

For FlashRunner I, II, III programmers a cable interface is available as an external accessories:

• FR01INTF01

Cable

For FlashRunner programmers, different length special ISP communication cables are available.

Cable Adapters

For FlashRunners programmers two cable adapters are available:

• FRHDRDB15 for DB15 connector
• FRHDRPSTR for Wire Wrap Strip

FlashRunner Cube

For FlashRunner Cube relay barriers modules are offered as an external accessories:

• FRC_RB_04 - Relay barrier module for 2 and 4 channel units - FRC_GP_02 and FRC_GP_04
• FRC_RB_08 - Relay barrier module for 8 channel unit FRC_GP_08

FlashRunner Cube Demultiplexers

For FlashRunner Cube demultiplexer modules with integrated relay barriers are offered as an external accessories:

• MPX 160 K-22 - x2 demultiplexer for 2 channel unit (4 channels)
• MPX 160 K-23 - x3 demultiplexer for 2 channel unit (6 channels)
• MPX 160 K-24 - x4 demultiplexer for 2 channel unit (8 channels)
• MPX 160 K-42 - x2 demultiplexer for 4 channel unit (8 channels)
• MPX 160 K-43 - x3 demultiplexer for 4 channel unit (12 channels)
• MPX 160 K-44 - x4 demultiplexer for 4 channel unit (16 channels)
• MPX 160 K-82 - x2 demultiplexer for 8 channel unit (16 channels)
• MPX 160 K-83 - x3 demultiplexer for 8 channel unit (24 channels)
• MPX 160 K-84 - x4 demultiplexer for 8 channel unit (32 channels)

Power Adapters

For the traditional FlashRunner there arr offered following power adapters:

• SPA001 - 12V 16W AC/DC Switching Power Adapter With Striped Cord
• SPA002 - 12V 36W AC/DC Switching Power Adapter With 2.1mm Jack
• SPA003 - 7.5V 15W AC/DC Switching Power Adapter With 2.1mm Jack
• SPA004 - 12V 60W AC/DC Switching Power Adapter With Striped Cord

Flashrunner I Algorithms

In general licenses for programming algorithms for particular devices are offered separately as:

• Single licenses:
• PA01STD0 - single Programming Algorithm for standard mass market device
• PA01NMM0 - single Programming Algorithm for specialized no mass market device
• Credits:
• PA-STP_01 - five free of choice Programming Algorithms for standard devices to be download within one year since the invoice date.
• PA-STP_02 - ten free of choice Programming Algorithms for standard devices to be download within one year since the invoice date.
• PA-STP_03 - fifteen free of choice Programming Algorithms for standard devices to be download within one year since the invoice date.
• Packages:
• PA01xxx - Programming Algorithms for all currently supported standard devices from selected silicon vendor
• PA01GEN0 - Programming Algorithms for all currently supported standard devices from all supported silicon vendors

The price of last two packages covers in addition one year of maintenance. It gives rights to download/upgrade algorithms 2 times within one year since the invoice date. The maintenance can be prolonged or renewed for the following year starting invoice date respectively with:

• AMP-SCP - Advanced Maintenance Program for all supported devices from selected silicon vendor
• AMP-GEN - Advanced Maintenance Program for all supported devices from all supported silicon vendors

All above is applied to all FlashRunners except series II and III. In case of FlashRunner Series II and III the selected package PA01xxx is included in the price. During the whole programmer lifetime, it can be upgraded only for the devices from the same silicon vendor by purchasing AMP-SCP.

There is also useful system software available that can be downloaded from web (icon on the right margin).

FlashRunner I (single channel)

• single-channel ISP programmer;
• universal;
• programming algorithms offered separately;
• single channel FlashRunner I is available in following variants:
  • FR01ENG – base unit;
  • FR01EXP01 – set of base unit and evaluation board;
  • FR01LAN – unit for integration i.e. in ATE;
• interface: RS-232;
• stand-alone and remotely controlled by PC modes;
• power supply 9 - 24V DC
  (supplier not included);
• supports BDM, JTAG, SPI, I2C, MON, ICC, SCI, … protocols;
• supports a wide spectrum of components and manufacturers;

FlashRunner I (multi-channel)

• 8-channels ISP programmer
  (demultiplexed 1 x 8 channels);
• universal;
• programming algorithms offered separately;
• unit for integration within ATE
• interface: LAN, RS-232;
• stand-alone and remotely controlled by PC modes;
• power supply 9 - 18V DC
  (power supplier not included);
• support of most ISP protocols (BDM, JTAG, SPI, I2C, MON, ICC, SCI, UART);

FlashRunner II (FR02xxxx)

• single-channel ISP programmer;
• specialized;
• unit for integration within ATE;
• interface: LAN, RS-232;
• stand-alone and remotely controlled by PC modes;
• power supply 9 - 24V DC
  (supplier not included);
• supports BDM, JTAG, SPI, I2C, MON, ICC, SCI, … protocols;
• programming algorithms for selected semiconductor vendor or serial memories included in the price – upgrade to others not possible;

FlashRunner III (FR03xxxx)

• low-cost;
• single-channel ISP programmer;
• specialized;
• limited unit for integration within ATE;
• interface: RS-232;
• stand-alone and remotely controlled by PC modes;
• power supply 7,5V DC
  (supplier not included);
• supports BDM, JTAG, SPI, I2C, MON, ICC, SCI, … protocols;
• programming algorithms for selected semiconductor vendor or serial memories included in the price – upgrade to others not possible;
• other limitations compare to FlashRunner II programmer:
  • no optoizolation
  • one programmable voltage output (0 - 5,5V; 0,5A)
  • no analog input
  • no clock and calendar
  • no input lines for project selection
  • no input line stop
  • no report files
  • limited project scripts

FlashRunner Quatro

• 4-channel (FR04A04) / 8-channel (FR04A08) / 16-channel (FR04A16) ISP programmer (demultiplexed 1/2/4 x 4 channels)
• universal;
• programming algorithms offered separately;
• unit for integration within ATE;
• interface: LAN, RS-232;
• stand-alone and remotely controlled by PC modes;
• power supply 9 - 18V DC
  (power supplier not included);
• support of most ISP protocols (BDM, JTAG, SPI, I2C, MON, ICC, SCI, UART);

MicroPlexer

MPX160A MicroPlexer is a ISP signal switch that allows one ISP programmer to support multiple targets. It has a convenient wide-range power supply input and three working modes with up to 32 output ISP channels.

Depending on the working mode, each of the ISP channels is composed of:

• Either 6 or 3 digital, bidirectional lines;
• Either 2 or 1 analog/digital lines;
• Either 2 or 1 power lines;
• 1 ground line (common for all channels).

MicroPlexer is controlled via either ASCII-based commands via its RS-232 interface or via control lines. ASCII commands allow for selecting the output channel or to disconnect all of the output channels.
